  All Products   Protective Barriers   Guard Rail Systems   Structural Guard Rails (drop-in and bolt-on style) GR-F3R-GBS-4-YL
GR-F3R-GBS-4-YL

Steel Hinged Guard Rail 41.875 In. Length 3 Ribbed Gate Yellow

Sometimes personnel need access to what a guardrail is protecting. A swinging guard rail gate is the perfect solution. When closed the gate acts just like the rest of the guard rail, but it has a sleek connection and can swing freely. Simple opening and closing for quick entry and exit. Steel construction maintains strength during the wear and tear of daily use. Powder-coated finish for durability and strength. Hardware is included. Additional posts are available and sold separately. If adding a rail to an existing rail and post section, only a single post is needed.
Contact Vestil QuickShip Non-Returnable
Key Features
  • Designed for simple opening and closing
  • Yellow baked-in powder-coated finish for added toughness
  • Three ribbed design for added height protection
  • Gate includes rail with black hinge brackets
Product Image

Visual Reference

GR-F3R-GBS-4-YL
GR-F3R-GBS-4-YL
GR-F3R-GBS-4-YL
GR-F3R-GBS-4-YL
GR-F3R-GBS-4-YL
GR-F3R-GBS-4-YL
GR-F3R-GBS-4-YL
GR-F3R-GBS-4-YL
GR-F3R-GBS-4-YL
Quick Actions

Product Resources

Image Gallery View product images Contact Vestil Ask about this product
Product Data

Core Data

Assembled Weight 45 lbs
Assembled Size 51"W x 6"L x 15"H
Total Ship Weight 61 lbs
Package 1 Size 15"W x 42"D x 15"H
Color / Finish Yellow Rail / Black Hinge Bracket
Freight Type Parcel

Additional Attributes

Impact Capacity (Lbs.) 10,000
Hardware Included Yes
Documents

PDFs & Product Files

  Approval Drawing   Testing Certificate   360 Image   90 Days Warranty
Extended Product Details
Copyright © 2026 All Rights Reserved, Vestil Manufacturing Corp.

Details For Model: GR-F3R-GBS-4-YL

GR-F3R-GBS-4-YL

Steel Hinged Guard Rail 41.875 In. Length 3 Ribbed Gate Yellow

Sometimes personnel need access to what a guardrail is protecting. A swinging guard rail gate is the perfect solution. When closed the gate acts just like the rest of the guard rail, but it has a sleek connection and can swing freely. Simple opening and closing for quick entry and exit. Steel construction maintains strength during the wear and tear of daily use. Powder-coated finish for durability and strength. Hardware is included. Additional posts are available and sold separately. If adding a rail to an existing rail and post section, only a single post is needed.

  • Designed for simple opening and closing
  • Yellow baked-in powder-coated finish for added toughness
  • Three ribbed design for added height protection
  • Gate includes rail with black hinge brackets

Core Data

Assembled Weight: 45 Assembled Size: 51"W x 6"L x 15"H Color: Yellow Rail / Black Hinge Bracket
Total Ship Weight: 61 Package 1 Size: 15"W x 42"D x 15"H Freight: Parcel

Specifications

Impact Capacity (Lbs.): 10,000
Hardware Included: Yes
