ASP-36-3-HR

Steel Adjustable Step Stand 36 inches Wide 3-Step with Handrails 500 Lb. Capacity Yellow

The adjustable step-mate stand can be used as either a comfortable worker platform or a semi-permanent step. Step angle is maintained at a stable 30 degrees. Built of powder coated welded steel with schedule 40 steel handrails. Do not use the stand if it cannot be leveled properly or remains unstable despite adjusting the legs appropriately.
Contact Vestil Non-Returnable
Key Features
  • Independently adjustable height legs
  • Handrails included for user stability
  • Each leg fitted with rubber tip for better grip & traction
  • Serrated step surface provides excellent traction
New Product Images Coming Soon - Design change
Product Image

Visual Reference

ASP-36-3-HR
ASP-36-3-HR
Quick Actions

Product Resources

Image Gallery View product images Contact Vestil Ask about this product
Product Data

Core Data

Assembled Weight 128 lbs
Assembled Size 38.8125"W x 33.875"L x 52"H
Total Ship Weight 148 lbs
Package 1 Size 40"W x 48"D x 39"H
Color / Finish Yellow
Freight Type LTL Palletized

Additional Attributes

Usable Width (in.) 36-11/16
Number of Steps 3
Uniform Capacity (lb.) 500
Bottom Step Height Minimum (in.) 6
Bottom Step Height Maximum (in.) 8-1/4
Middle Step Height Minimum (in.) 13
Middle Step Height Maximum (in.) 15-1/4
Top Step Height Minimum (in.) 20
Top Step Height Maximum (in.) 22-1/4
Step Material Serrated Steel
Step Depth (in.) 11-3/4
Step Angle (degrees) 20 to 22-1/4
Leg Feature Anti-Slip Tips
Adjustable Legs (Y/N) Yes
Handrail Construction Steel Tubing
Includes 2 Bolt-On Handrails
Documents

PDFs & Product Files

  Approval Drawing   Testing Certificate   Owner Manual   90 Days Warranty
Extended Product Details
Copyright © 2026 All Rights Reserved, Vestil Manufacturing Corp.

Details For Model: ASP-36-3-HR

ASP-36-3-HR

Steel Adjustable Step Stand 36 inches Wide 3-Step with Handrails 500 Lb. Capacity Yellow

The adjustable step-mate stand can be used as either a comfortable worker platform or a semi-permanent step. Step angle is maintained at a stable 30 degrees. Built of powder coated welded steel with schedule 40 steel handrails. Do not use the stand if it cannot be leveled properly or remains unstable despite adjusting the legs appropriately.

  • Independently adjustable height legs
  • Handrails included for user stability
  • Each leg fitted with rubber tip for better grip & traction
  • Serrated step surface provides excellent traction

Core Data

Assembled Weight: 128 Assembled Size: 38.8125"W x 33.875"L x 52"H Color: Yellow
Total Ship Weight: 148 Package 1 Size: 40"W x 48"D x 39"H Freight: LTL Palletized

Specifications

Usable Width (in.): 36-11/16
Number of Steps: 3
Uniform Capacity (lb.): 500
Bottom Step Height Minimum (in.): 6
Bottom Step Height Maximum (in.): 8-1/4
Middle Step Height Minimum (in.): 13
Middle Step Height Maximum (in.): 15-1/4
Top Step Height Minimum (in.): 20
Top Step Height Maximum (in.): 22-1/4
Step Material: Serrated Steel
Step Depth (in.): 11-3/4
Step Angle (degrees): 20 to 22-1/4
Leg Feature: Anti-Slip Tips
Adjustable Legs (Y/N): Yes
Handrail Construction: Steel Tubing
Includes: 2 Bolt-On Handrails
